Grab Bucket EOT Crane
Grab bucket EOT crane is a specialized overhead bridge crane with a grab bucket, ideal for efficiently loading, unloading and transferring bulk materials like coal and minerals. Widely used in ports, mines and more, it saves labor, reduces time and ensures safe, high-productivity operations.
- Lifting Capacity(ton):1~32 ton
- Lifting Speed(m/min):5 m/min
- Span:4.5-28.5 meter
Product Description:
Grab bucket EOT crane is a specialized overhead bridge crane integrated with a grab bucket, designed for efficient loading, unloading, and transferring of bulk and granular materials. Combining advanced crane technology with automated grab mechanisms, it eliminates manual labor, reduces auxiliary time, and ensures safe, high-productivity operations in various industrial scenarios.
As a core equipment in material handling, grab bucket EOT cranes are widely used in ports, docks, mines, metallurgical plants, cement factories, waste treatment centers, and power plants. They excel in handling materials such as coal, minerals, sand, gravel, grain, scrap steel, garbage, and biomass, making them indispensable for bulk material-intensive industries.
Grab Bucket EOT Crane Parts:
-
01
Three Phase Induction Motors
EOT cranes widely use three phase induction motors, which provide stable and powerful driving force for the operation of the crane, ensuring smooth lifting, lowering, and movement of the grab bucket.
-
02
Grab Mechanism
Composed of grab jaws, connecting rods, and driving devices, it is specially designed to clamp, hold, and release various bulk materials. The jaws are made of high-strength wear-resistant steel to withstand the friction and impact of materials.
-
03
Electrical Control System
Includes controllers, contactors, and buttons, which coordinate the operation of motors, hoists, and trolleys. It enables precise control of the crane's speed, direction, and grab action, ensuring safe and efficient work.
-
04
Girders
There are single girder and double girder options. The single girder is a box-type or I-beam structure, lightweight and cost-effective, suitable for medium and small load operations with shorter spans. The double girder, consisting of two parallel main girders, has higher rigidity and load-bearing capacity, making it ideal for heavy-duty operations and longer span working conditions.
Custom Grab Bucket EOT Cranes:
For accurate customization of your Grab Bucket EOT Crane, please provide the following technical specifications so our engineering team can design the most efficient and reliable solution for your needs:
-
Lifting Capacity:
5–60 tons, selected according to your actual operational requirements.
-
Span and Track:
4.5–28.5 meters, with the main beam span specified based on your factory layout.
-
Working Environment:
Include details on temperature, humidity, dust levels, and any special operating conditions so we can recommend the right protection grade and materials.
-
Lifting Height & Travel Speed:
Define the maximum lifting height and desired operating speeds.
-
Power Supply & Control Method:
Specify available voltage, frequency, and preferred control mode (pendant, remote control, or cabin operation).
Send us your project details today, and we will provide a tailor-made Grab Bucket EOT Crane solution with professional recommendations.
Parameter:
| Lifting capacity(t) | 5 | 10 | 16 | 20 | |
| Span(m) | 10.5-31.5 | 16.5-31.5 | |||
| Lifting height(m) | 20 | 18 | 28 | 26 | |
| Working class | A6 | ||||
| Speed | Hoist lifting | 39.2 | 40.7 | 41.8 | 48.6 |
| (m/min) | Trolley traveling | 44.6 | 45.9 | 38.0 | 37.8 |
| Crane traveling | 93.6/113.6 | 112.5/101 | 88/87.3 | 87.3 | |
| Power supply | 380V, 50HZ, 3 phase or others | ||||
